High efficiency and cost-effective Factory Price Dry Type Fish Feed Extruder Pellet Making Floating Fish Feed Extruder
Product Details:
| Place of Origin: | China |
| Brand Name: | MIKIM |
| Certification: | CE |
| Model Number: | DGP-40,DGP-60,DGP-70,DGP-85,DGP-90 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | $1500.00 - 35000.00/ Set |
| Packaging Details: | packed by wooden export package or loading by container |
| Delivery Time: | 7-10 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 300 sets per month |
|
Detail Information |
|||
| Moulds: | Various Shapes Can Be Choosen | Food Material: | Meat,beans,vegetable And So On |
|---|---|---|---|
| Spare Parts: | 1 Set | Operation: | Simple Automatic Operation |
| Motors: | Chinese Brands, Siemens, ABB | Processing Type: | Extrusion |
| Inveter: | ABB | ||
| Highlight: | dry type fish feed extruder,floating fish feed pellet machine,factory price pet food extruder |
||
Product Description
High Efficiency and Cost-Effactory Dry Type Fish Feed Extruder
Electric Fish Feed Extruder Machine
Our advanced electric fish feed extruder machine offers superior performance and reliability for aquaculture feed production.
- Variable frequency feeding device with speed adjustment prevents hopper reef knots and ensures precise feeding
- Minimal residual material with easy cleanup and maintenance
- Novel design with simple structure for easy operation and parts replacement
- Primarily used for extruding corn, soybean and other raw materials
- Suitable for high-grade livestock and aquaculture feed production
- Available in small, medium, and large extruder sizes or complete units based on customer requirements
Final Pellet Production
Our fish feed production equipment can produce a variety of flower-shaped pellets. The product outlet features a frequency conversion speed control rotary cutting device with adjustable blade rotation speed to precisely control cutting speed and length.
Technical Specifications
| Model | DGP-40 | DGP-60 | DGP-70 | DGP-85 | DGP-90 |
|---|---|---|---|---|---|
| Capacity (kg/h) | 40-50 | 120-150 | 200-250 | 300-350 | 400-450 |
| Main Motor (HP) | 12 | 25 | 30 | 35 | 50 |
| Feeder Motor (kW) | 0.4 | 0.4 | 0.4 | 1.5 | 1.5 |
| Cutter Motor (kW) | 0.4 | 0.4 | 0.4 | 0.55 | 0.55 |
| Screw Diameter (mm) | φ40 | φ60 | φ70 | φ80 | φ90 |
| Machine Size (m) | 1.4×1.25×1.2 | 1.47×1.12×1.25 | 2.05×1.4×1.3 | 2.15×1.5×1.3 | 2.2×2×1.35 |
| Weight (kg) | 360 | 560 | 740 | 850 | 1200 |
Packaging and Shipping
MIKIM prioritizes machine safety during transportation. Before delivery, each machine is wrapped with plastic film to prevent water, moisture, and rust, and secured with metal framing. Complete container reinforcement ensures safe transit, with MIKIM providing comprehensive support throughout the entire shipping process.
Our Services
- Detailed introduction of wet type advanced design fish food extruder machines based on client capacity requirements
- Comprehensive information sharing including detailed pictures, videos, and technical specifications
- Custom design of floating fish food extruding lines
- Assistance with suitable floating fish feed formulations
- Comprehensive instruction manuals and operational videos for machine operation
Customer Visits
Qualifications and Awards
Product Video
Want to Know more details about this product
