Automatic Peanuts Bar / Chocolate Bar / granola bar machine 200 - 400kg/hr

Automatic Peanuts Bar / Chocolate Bar / granola bar machine

The production line adopts advanced mechanical structure, combined with traditional requirements, and cooperates with electric PLC operating system to achieve full automation, reduce production cost, improve production efficiency, continuous feeding, automatic flattening, automatic slitting, cross cutting, double The road is automatically leveled, the leveling density is adjustable, the thickness is uniform, the frequency conversion is adopted, the cutting size is accurate, and the forming is good. The whole machine is continuously produced, and no manual connection is required in the production process to realize fully automatic and intelligent operation.

If you are interested in our machine,please tell us your raw material,your capacity and your budget,we can provide suitable processing line for you.
Nougat machine usually can make peanut nougat, sesame nougat, almond nougat, pine nuts nougat, chocolate nougat, cranberry nougat, strawberry nougat, mango nougat, matcha cow Sugar rolling, etc.

(1) Peanut candy making process:
Roasting → peeling → boil sugar → mixing → flating → cutting → cooling → packaging.

(2) Sesame bar production process:
Cleaning and peeling → boil sugar → mixing → flating → cutting → cooling → packaging.

(3) Rice candy production process:
Puffing → boil sugar → mixing → flating → cutting → cooling → packaging.

(4) caramel bar production process:
Knead the dough → press the dough → cut noodles → frying→ boil sugar → mixing → flatting→ cutting → cooling → packaging.
Features:
*The main control circuit adopts imported single chip microcomputer, man-machine interface, frequency conversion control, the parameter setting is convenient and quick, the operation is centralized and intuitive, fully realize the humanized automatic operation control;
*High photosensitive electronic eye automatic accurate tracking, feedback information accurate, error is minimal;
*Stable operation, automatic shaping, automatic material conveying and automatic cutting;
*Simple operation, low labor intensity;
*Continuous production, high yield;
*Mechanical transmission system structure compact layout reasonable;Clear circuit, no need for direct maintenance

Mixing machine:

The mixer is suitable for making peanut candy, sesame sugar and various cereal grains.
When using, just put the hot things in the cooler and slowly pour them into the sugar pot.
The machine adopts far-infrared heating and uniform heating; the pneumatic lifting device makes discharge more convenient; PP sheet scraping has the characteristics of non-stick, easy to fall off and low noise.

Forming machine:

The automatic Shaqima forming machine consists of a mixer, feeder, spreader, agitator, spreader, cooling flow pump and automatic cutting machine. It is suitable for cereal bars, scones, rice sugar, melon seeds, peanut cakes, sesame cakes, egg tarts, nutrition bars, hard shaqima, frozen rice sugar and other snacks.
The whole machine adopts frequency conversion speed regulation synchronization, PLC controls cutting length, multi-pass roller flattening, control molding temperature, accurate cutting length, uniform product weight, uniform and continuous production of the whole machine, and can realize automatic and intelligent operation.
Advantages:
1. made of stainless steel for national food hygiene requirements.
2.with simple operation, saving time and Labour
3.producing in large quantity, cutting for good shape, adjusting length arbitrarily.
Technical Parameter:
