Nutritional Powder Processing Line / baby food maker machine with CE Standard
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | DARIN |
| Certification: | CE ISO9001 |
| Model Number: | DR-65/70 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | negotiation |
| Packaging Details: | Standard export wooden cases, wrapped with film firstly, then packed with strong wooden cases, |
| Delivery Time: | 30 working days after received your payment |
| Payment Terms: | T/T or L/C |
| Supply Ability: | 50 sets per year |
|
Detail Information |
|||
| Product Name: | Nutrition Powder Extruding Line | Application: | The Processing Line Can Produce Nutrition Powder In Good Quality. |
|---|---|---|---|
| Condition: | New | Layout: | AutoCAD Format According To Client’s Workshop |
| Manual: | English Version | Standard: | CE |
| Commissioning Service / Training: | Provide, But Paid By Buyer | After-sales Service: | Full Life |
| High Light: | rice powder making machine,baby food maker machine |
||
Product Description
Hot Sale Nutritional Powder Processing Line/baby food production line/making machine
Nutritional powder potato rice corn bean modified starch production line is developed to meet the demands of nutrition food. This machine adopts rice flour, corn flour, soybean flour and other nutrition grains flour as raw materials. It has features which are popular with food manufacturers, such as high automation, easy operation, without leak of powder dust, sanitation, saving energy and easy to add all kinds of raw materials and nutriments
2. The model is DR-70, the output is 200-250kg/h.
3. Extruder screws quantity is two.
4. The main body material is stainless steel, which is easy to be cleaned.
5. The screws material is 38CrMoAl, which is wear-resisting.
6. The processing line needs two workers to operate.
7. We advice the plant area is no less than 110 square meters, the length is no less than
22 meters.
8. Process flow: (Raw material)---mixing---conveying---extruding & puffing---conveying---drying--- (milling---packing)
9. Equipments: Mixer---Screw conveyer---Extruder---Air conveyer---Dryer--- (Grinder---Packing machine)
10. The temperature and rotating speed can be controlled and adjusted.
11. The processing line has self-cleaning function.
12. Parameters:
|
Model |
Installed power |
Real power |
Output |
Dimension |
|
DR65 |
66kw |
50kw |
100-150kg/h |
19000x1200x2200mm |
|
DR70 |
100kw |
67kw |
200-240kg/h |
21000x1500x2200mm |
|
DR85 |
130kw |
80kw |
400-500kg/h |
30000x3500x4300mm |
It is used to produce infant baby food and some other instant flour products. The raw material is put in the mixer then mixed ingredients are fed into extruder feeder. The extruder is fitted with: special cylindrical holding silo; vibratory doser with hopper to feed the extruding screw; extrusion mechanism and cutting; independent electric panel.
After the extrusion the product is conveyed till the continuous rotary drier through a pneumatic conveyor. The continuous rotary drier has a heat exchanger with gas burner that allows a better heating of the product and it is economically viable owing the low cost of electric power. Case the client prefers we have the electric drier also.
1. The motor of our extruder machine is Siemens Motor.
2. The raw material of our machines is Stainless Steel.
3. Our automatic machines are controled by frequency changer, it is easy to operate.
4. Our factory will send our engineer to install machines for you.
5. baked snack machine have the 12 months guarantee time.
6. The machine is multifunction. Many types of snacks can be manufactured by changing
the die head and model.
FAQ
1.Where is your company situated?
Our factory located in Jinan, Shandong Province, China.
You can take plane to Jinan International Airport, or take high-speed rail to Jinan West
Station , Jinan Station ,we will pick you up to our factory.
2.What is your payment term?
You can transfer the payment via T/T. Generally, 30% advance to start to produce,
70% balance should be paid before shipping.
3. What capacity do you want ?
We have different capacity like 100kgs/hr. Please tell your requirement about the capacity so will make exact quotation for you.
If you are interested in our machine , please contact me .
Exhibition show
