Product Details:

Place of Origin: Jinan,Shandong Province
Brand Name: DARIN
Certification: CE Certificate
Model Number: DRD-100/DRD-300

Payment & Shipping Terms:

Minimum Order Quantity: 1 sets
Price: USD 28000~ USD 35000
Packaging Details: We could supply Export Standard Wooden Case, suitable for long trip and loading & unloading.
Delivery Time: 45 working days after receiving the down payment
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 50 Sets per year
Get Best Price Contact Now

Detail Information

Condition:: New Model Number:: DRD-100/DRD-300
Application:: Dog Snacks/ Pet Treats Brand Name: Darin
Motor: WEG Motor With 3 Year Warranty All Over The World PLC & Touch Screen: Simens
Electric Parts: ABB Or Schneider Certificate: CE/ISO9001
High Light:

pet extruder machine

,

dog food making machine

Product Description





Dog Food Equipment/dry Pet Dog Food Processing Plant extruder for pet food
1. Introduction:

Flow chart: Raw Material Mix – Screw Conveying – Extruding – Cooling – Cutting – Drying -- Cooling



Comparison between Darin and Other Suppliers, our machine has advantdages as followed:
1. Motors are from WEG, Germay, which has 3-year world-wide guarantee;
2. Electric parts are from ABB or Schneider, easy to find replacments at local market;
3. PLC and touch screen are from Siemens, Germany to realize easier operation and less labor quantity;
4. PLC and touch scrren controls whole processing line, not one or two single equipment;
5. While faults occurred, relevant information will be displayed on touch screen, easy to settle the problem;
6. Control cabinet has 24V safe voltage (not 220V), which could protect the operator even electric leakage occurred;
7. Three kinds of protectors to keep machine and operator safe: over-current protector, over-voltage protector and over-heat protector;
8. All the cover body, mesh belt and parts touching with materials or final products are made by stainless steel 304.



Technical Parameters

Model Capacity Power Dimension Worker needed
DRD-100 100-150kg/hr 81kw 18x5x3m 2-3
DRD-300 200-260kg/hr 95kw 20x5x3m 2-3


In order to increase the protein and other nutrients for our pet,Automatic dry dog pet food machine/processing line use meat powder,grains,beans and vegetables as raw materials to produce pet food with new shape, unique taste to let them live healthier.

1. Mixer blending all ingredients like corn flour,soybean flour, fish meal, bone/meat meal, water according to the accurate formula to make dry floating & sinking fish feeds , pet dog cat feed pellets with various daimeter 1mm, 1.5mm, 3mm, 5mm, 8mm, 10mm, 15mm, 20mm, etc.
Fish Feed Pellets Floating Time: 24 hours after baked dry completely with oil coated, also healthy for fish body growing, especially for salmon tilapia,catfish,trout,etc
2. Extrusion will male all materials cooking extrusion under the high temperature & pressure insde of the extruder barrel, with twin-screw high speed rounding. Then shaping the feeds into the fixed shape .
3. Drying processing we make sure every single feed pellets completely dry with our drying ovens which has the specially design hot air recelying system, supports electric/oil/gas/steam power resource type only suitable and cost saving for your local power conditions.
4. Flavoring line can be supply the feeds with oil , healthy for fish or other animals digestive absorption
Also can be added some other vitamins, minerals.
5. Cooling & packing, our package machine can be various 0.5-50kg/bag, range packing weight for your different markets needs, longer shelf life for final feed prodcuts.



Our Services


Q1: If we buy machines, what is the after-sale service?
Jinan Darin Machinery Co., Ltd. will send the engineer to buyer’s factory.
Offer the trainee program, start the related food production as customer request.

Q2: If machines wearable parts need to change, what should we do?
Jinan Darin Machinery Co., Ltd. will offer the wearable parts all the time.
And offer the on-line video instruction for the operation.

Q3: What is the payment terms if we want to buy the machines?
Usually it is 30% by T/T, pay the balance by T/T before delivery or L/C at sight
