Product Details:

Place of Origin: Jinan,Shandong Province
Brand Name: DARIN
Certification: CE Certificate
Model Number: DRD-100/DRD-300

Payment & Shipping Terms:

Minimum Order Quantity: 1 sets
Price: USD 28000~ USD 50000
Packaging Details: Darin packs the machine with export standard fumigation wooden cases, which is strong ans suitable for long-distance and multi-times loading & unloading by forklift.
Delivery Time: 60-65 working days after receiving the down payment
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 50 Sets per year
Get Best Price Contact Now

Detail Information

Condition:: New Model Number:: DRD-100/DRD-300
Application:: Dog Snacks/ Pet Treats Brand Name: Darin
Material: SUS304 Motor: WEG Motor
PLC & Touch Screen: Simens Electric Parts: ABB Or Schneider
Guarantee: 1 Year
High Light:

pet extruder machine

,

dog food making machine

,

SUS304 Food Production Line

Product Description

Dog Treats/Dog Chewing/Detal Care treats Food Production Line



Dog Treats / Dog Chewing / Detal Care Treats Food Production Line 0



1.Technical Parameter

Model DRD-100 single screw extruder DRD-300 single screw extruder
Installed capacity 38kw 54kw
Power consumption 28kw 30kw
Output 100-150kg/a 200-250kg/h
Size 12000*1200*2000mm 13000*1200*2000mm





2.Introduce:
Pet treats food takes starch as raw materials with scientific configuration and was extruded from co-extruder, it can be made into many kind of shapes such as stick,bone,bi-color,bi-flavor, etc. This kind of food not only provide protein,fat,vitamin ,nutrition for dogs, but also satisfy the dog nature hobby.It has following features: strong teeth,clean mouth and teeth. The products can be in many shapes, like twist, bi-colors, core-filling and so on.



3.Materials: adopts corn flour, bone meal, fish meal as raw materials

Dog Treats / Dog Chewing / Detal Care Treats Food Production Line 1



4.Capacity: 100kg/h 200kg/h



5.Voltage: Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to customers' Local voltage according to different countries



6.Process and follow chart
Mixer---Screw conveyor--- Single screw extruder---Cooling machine---Cutting machine--- Hoister



7.Technical Parameters



Model Capacity Power Dimension Worker needed
DRD-100 100-150kg/hr 81kw 18x5x3m 2-3
DRD-300 200-260kg/hr 95kw 20x5x3m 2-3



8. Payment term:

1. 40% of total payment as the deposit,we will finish the machine within 40 days.

2. 60% of total payment before making delivery the Equipment to Buyer’s plant.

Package: Wooden case for export, fit for multiple handing and long distance marine shipping.

Delivery time: Seller should get all the goods ready and ship the goods to the destination port within 40 days after receiving the total amount price.

Quality guarantee terms: equipment shall be guaranteed 12 month, without destroyed by some people. Enclosed the whole line, we will give you some spare parts, such as heating ring, spanner, etc. for free. The spare parts shall be supplied at preferential price for an extended long time.

Installation and training: we will send our engineer to install and train in your company, on condition that you should supply the go and return air tickets, the accommodation, the food for our engineers and also pay USD100 each person per day.

9. CE certificate:

Dog Treats / Dog Chewing / Detal Care Treats Food Production Line 2

10. Interzoo 2018 Exhibition

Dog Treats / Dog Chewing / Detal Care Treats Food Production Line 3

Dog Treats / Dog Chewing / Detal Care Treats Food Production Line 4
