High Efficiency Automatic Cheese Puff Snack Machine SS304 3phases Grain Puffing Machine
Product Details
| Condition: | New | Dimension(L*W*H): | 2150*1500*2300 |
|---|---|---|---|
| Voltage: | 380v, 50hz, 3phases (adjustable) | Warranty: | 12 Months |
| Applied: | Corn Puff Snack Extruder | Material: | SS304 |
| Manual: | English Version | Capacity: | 120-150kg/h,200-250kg/h,400-500kg |
| Highlight |
cheese puff snack machine,puff snack machine ss304,3phases grain puffing machine |
||
Product Description
High Efficiency Automatic Cheese Puff Extruder Machine / Production Line
1. Introduction
Puffed Snacks System is a new type of extruding food processing line designed and developed by ourselves on the basis of learning from advanced technology in the world so that its technical performance and quality of products both reach to the most advanced in the world. This line will finish mixing, extruding, cutting, spraying and producing in one-pass operation automatically. This line features lots of types, flexible collocation, extensive applied materials, various products and easy operation.
2. Raw Material
Corn flour,wheat flour, rice flour, oat meal, other grain meals
3. Flow Chart
Our company has rich experiences. We are able to supply turnkey project including grinding system for raw material, production machines for cereal, packing system for final products, even other lab testing equipments, etc.
Flour Mixing – Extrusion – Drying – Flavoring – Packing
4.Technical Parameters
| model | installed power | power consumption | output | size |
| MK65 | 81.5kw | 53kw | 120-150kg/h | 21000x1200x2200mm |
| MK70 | 116kw | 76kw | 200-250kg/h | 23000x1500x2200mm |
| MK85 | 181kw | 117kw | 400-500kg/h | 28000x3500x4300mm |
1. The screw is made of alloy (38CrMoAL) by nitriding process, high strength and
wear-resting. And it has good self-cleaning ability and does not need to discharge or
clean the barrel and screw, when roasting or replacing of materials.
2. The extrusion barrel is constructed of carbon steel, is made by #45 steel, stainless steel
coating.
3. Radiator is increased on driving part for forced cooling effect, and it ensures extruder
operate safely.
4. Cutting knife fixed in the die head seat, rotary cutting by V-belt drive.
5.The gearbox has automatic lubrication function, with extends gear life.
6. Main Motor from SIEMENS(CHINA), ensure its Powerful Extrusion and Excellent
Performance.
Why You Must Choose Us
1. Big Capacity Feeding Hopper, Variable Frequency Speed, Two Stages Mixing Wings ensure the Fast and Efficient Mixing and Feeding.
2. Double Axis Differential Conditioner, Available for Steam, Pre-cooking and High Efficient.
3. Linear Slide Face Cutting System, Strong Power, Variable Frequency Speed and Large Output,
4. Unique Designed Square Barrels, Made by Hard Carbide Sleeve, Hard-wearing and Durable.
5. Modular Circular Groove Screws, available for Different Extrusion Rate Applications.
6. Steam Heating System, ensure the Most Efficient, Continuous and Stable Heating Effects.
7. World-famous Brands Electronic Apparatus used in the Controller Box, make sure the Extrusion Process Perfect.
8. Main Motor from SIEMENS(CHINA), 90KW, ensure its Powerful Extrusion and Excellent Performance.
Quick Details
Condition: New
Place of Origin: China (Mainland)
Brand Name: MIKIM
Model Number: MK65/MK70/MK85
Application: snack food / nutrition food/food
Power(W):30-150 kw
Dimension(L*W*H): 21000x1200x2200mm
Certification: CE/ISO9001
After-sales Service Provided: Engineers available to service machinery overseas
Packaging & Delivery
Packaging Details: Suitable for export wooden box
Delivery Detail: About 35 days after receiving the down payment
Our Terms and After-sale Service
1. Delivery time:40 days after we receive the deposits
2. Payment: 30% deposits, balance against copy of bill of lading or LC at sight
3. Installation and commision: seller will send 1 technician to buyer's factory, All expenses including visa, round trip tickets, daily accommodation will be on the buyer’s account
4. Warranty is for one year
5. Accessory and spare pats will be offered with the whole line
